4 PoE Switch 2 Uplink 120W Hi POE
Home / Products / IP Transmission / 100Mbps POE Ethernet Switch / Detail
4 PoE Switch 2 Uplink 120W Hi POE
6 port switch with 4 port PoE,100Mbit each port
PoE data & power transmission distance 100meters(100Mbps),
250meters(10Mbps)
Maximum 30 watts power for each PoE port
PoE Standard: IEEE 802.3af,IEEE 802.3at
PoE Pin: 1/2+,3/6-
Total Power:52V2.3A 120W
4 ports PoE Ethernet Switch is a security surveillance Ethernet Switch which aims at Ethernet high definition surveillance and security system. The product fully combines the characteristics of security surveillance, provides fast packet forwarding ability and abundant backplane bandwidth,which ensures clear image and fluent transmission. ESD and surge protection circuit can improve product stability. The product supports one key Extend mode, with VLAN function can restrain the network storm, protect the information security, prevent the viral transmission and cyber attack, fully satisfy the Ethernet video security surveillance system and Ethernet project needs.
|
Item: 10402POE-BP120 |
Description |
||
|
Power |
Power Adapter Voltage |
110-240V AC |
|
|
Consumption |
120W |
||
|
Network Connector |
Network Port |
POE Ethernet Port |
1~4 Port:10/100Mbps |
|
Ethernet port |
Uplink Port:10/100Mbps |
||
|
Transmission Distance |
1~4Port: 100Mbps:0~100m 10Mbps:0~250m |
||
|
Uplink port:0~100m |
|||
|
Transmission Medium |
Cat5/5e/6 standard network cable |
||
|
Network Switch |
Network Standard |
IEEE 802.3/802.3u, IEEE 802.3x,IEEE 802.1d |
|
|
Switching Capacity |
1Gbps |
||
|
Packet Forwarding Rate |
0.74Mpps |
||
|
MAC Table |
2K |
||
|
Power Over Ethernet |
POE Standard |
IEEE 802.3at |
|
|
POE Power Supply Type |
End-Span(1/2+;3/6-) |
||
|
PoE Power Consumption |
at≤30W(every port) |
||
|
LED Status Indicator VLAN/Extend |
POE Ethernet LED Indicator |
Power: 1 red light indicates that the power normal work |
|
|
POE: 4 yellow lights indicate that the POE is power on |
|||
|
Ethernet: 6 green lights indicate that the Ethernet link and act; |
|||
|
Environmental |
Working temperature |
0℃~55℃ |
|
|
Relative Humidity |
20~95% |
||
|
Storage temperature |
-20℃~70℃ |
||
|
Mechanical |
Dimension (L×W×H) |
201 mm *120 mm *41mm |
|
|
Color |
Black |
||
|
Weight |
631.1g |
||
|
Stability |
MTBF |
>30000h |
|
