250W 16 ports POE ethernet switch 100Mbps

Home / Products / IP Transmission / 100Mbps POE Ethernet Switch / Detail

250W 16 ports POE ethernet switch 100Mbps

.16 ports 100Mbit PoE Ports,2 Gigabit Uplink Ports,1 Port Gigabit SFP Port

.100meters(100Mbps),250meters(10Mbps),1 Gigabit Fiber Ports,Data transmission:depends on the optical module

.PoE Standard: IEEE 802.3af

.PoE Pin: 1/2+,3/6-

.Total Power:52V 4.8A 250W

Description of this 250m extend mode 16 port 100 Mbit POE Switch 2 Uplink 1 SFP

The 101603EXPOE-BP250 is compact 16 Port 100mbps Poe Switch, with 16ports supporting 10/100 Mbps POE Ports,2 ports supporting 10/100/1000 Mbps Uplink Ports,1port Gigabit SFP Auto-negotiation and Auto-MDI/MDIX,The 16 POE ports can automatically detect, effectively suppress network storms. 16 Port Ethernet Poe Switch Multiple cameras can be connected for easy wiring, saving wiring time and cost.

We are quite professional in the field of 100mbps poe switch manufacturing.The members of our team come from a variety of professional fields, so we can provide professional and standardized services to our customers.Our 250m Extend Mode Poe Switch and Ethernet Poe Switch with 2 Uplink has a world-leading manufacturing level and a reasonable price.

Specification of this 250m extend mode 16 port 100 Mbit POE Switch 2 Uplink 1 SFP

Item:101603EXPOE-BP250			Description
Power	Power Adapter Voltage		110-240V AC
	Consumption		250W
Network Connector	Network Port	POE Ethernet Port	1~16 Port:10/100Mbps
		Ethernet port	Uplink Port:10/100/1000Mbps
		SFP Port	SFP Port :10/100/1000Mbps
	Transmission Distance		1~16Port: 100Mbps:0~100m 10Mbps:0~250m
			Uplink port:0~100m
			SFP:depends on the optical module
	Transmission Medium		Cat5/5e/6 standard network cable
Network Switch	Network Standard		IEEE 802.3/802.3u, IEEE 802.3x,IEEE 802.1d
	Switching Capacity		9.2Gbps
	Packet Forwarding Rate		6.8448Mpps
	MAC Table		2K
Power Over Ethernet	POE Standard		IEEE 802.3af/at
	POE Power Supply Type		End-Span(1/2+;3/6-)
	PoE Power Consumption		Af=15.4W/30W(every port)
LED Status Indicator VLAN/Extend	POE Ethernet LED Indicator		Power: 1 red light indicates that the power normal work
			POE:16 yellow lights indicate that the POE is power on
			Ethernet:18 green lights indicate that the Ethernet link and act;
Environmental	Working temperature		0℃~55℃
	Relative Humidity		20~95%
	Storage temperature		-20℃~70℃
Mechanical	Dimension (L×W×H)		285 mm 180 mm 44mm
	Color		Black
	Weight		1647g
Stability	MTBF		>30000h
