75W 4 ports POE switch 1G 2 Uplink

Home / Products / IP Transmission / 1000Mbps POE Ethernet Switch / Detail

75W 4 ports POE switch 1G 2 Uplink

● 6 ports switch with 4 ports PoE,1000Mbit each port,2 Uplink

● PoE data & power transmission distance 100meters

● Maximum 15.4 watts power for each PoE port

● PoE Standard: IEEE 802.3af

● PoE Pin: 1/2+,3/6-

●Total Power:52V1.45A 75W

Description of this 6 Ports Switch With 4 Ports PoE 1000Mbit POE Ethernet Switch

G10402POE-BP75 is a compact 6 Ports Full Gigabit PoE Switch, it is specially designed for the application of high definition network security surveillance system.

The PoE switch provides 4 Gigabit downlink PoE ports support 802.3af/at and 2 Gigabit uplink ports. The total PoE power output is up to 75 watts. It’s widely used in surveillance monitor and Ethernet network solution.

Specification of this 6 Ports Switch With 4 Ports PoE 1000Mbit POE Ethernet Switch

Item			Description
Power	Power Adapter Voltage		110-240V AC
	Consumption		75W
Network Connector	Network Port	POE Ethernet Port	1～4 Port : 10/100/1000Mbps
		Ethernet port	Uplink Port : 10/100/1000Mbps
	Transmission Distance		1～4 Port : 10/100/1000Mbps:0 ~ 100m;
			Uplink port:0~100m
	Transmission Medium		Cat5/5e/6 standard network cable
Network Switch	Network Standard		IEEE 802.3, IEEE 802.3u,IEEE 802.1ab, IEEE 802.3x
	Switching Capacity		12Gbps
	Packet Forwarding Rate		8.93Mpps
	MAC Table		2K
Power Over Ethernet	POE Standard		IEEE 802.3af/at(PSE/PD)
	POE Power Supply Type		End-Span(1/2+;3/6-)
	PoE Power Consumption		af≤15.4W; at≤30W(every port)
LED Status Indicator VLAN/Extend	POE Ethernet LED Indicator		Power: 1 red light indicates that the power normal work
			POE: 4 yellow lights indicate that the POE is power on
			Ethernet: 6 green lights indicate that the Ethernet link and act;
Environmental	Working temperature		0℃~55℃
	Relative Humidity		20~95%
	Storage temperature		-20℃~70℃
Mechanical	Dimension (L×W×H)		201 mm 120 mm 41mm
	Color		Black
	Weight		609.2g
Stability	MTBF		>30000h
