450W 16 ports POE switch 1G 2 Uplink 2 SFP

Home / Products / IP Transmission / 1000Mbps POE Ethernet Switch / Detail

..
..
  • ..
  • ..
  • ..
  • ..

450W 16 ports POE switch 1G 2 Uplink 2 SFP

 20 ports switch with 16 ports 1000Mbit PoE, 2 Gigabit Uplink Ports,2 Gigabit SFP Ports
 PoE data & power transmission distance 100meters
 Maximum 30 watts power for each PoE port
 Uplink port:2 Gigabit Ethernet port,Transmission Distance up to 100m, 2 Gigabit Fiber Ports,Data transmission:depends on the optical module
 PoE Standard: IEEE 802.3af;IEEE 802.3at
 PoE Pin: 1/2+,3/6-
Total Power:52V 8.7A 450W
Description of this 20 Ports Ethernet Switch with 16 PoE Ports 2 Uplink 2 SFP

G101604EXPOE-BP450 is a Ethernet Switch With 16 PoE Ports , 2 Uplink Ports and 2 SFP Ports,  which is designed for the projects that requests smaller power than 15.4W.

As we all know, market normal Standards for POE Switch is 15.4W and 30W,Which means,even though your devices doesn't request 15.4W, you have to buy the normal standards like 15.4W.

It is actually a waste for such situation, which will also increase your projects cost imperceptibly.

In order to support clients to have more choices for different projects, we have launched some Small Voltage POE Switch, which is suitable for the projects that requests small power. It can meet the engineering requirements while saving your costs.We have many years of experience in manufacturing and sales ofProfessional Ethernet Switch Design.Our team is in a leading position in design, manufacturing and quality control.Our company has been operating for many years and our Professional Design Ethernet Switch has a good reputation among our customers.In addition to manufacturing, we also provide comprehensive after-sales service to make our customers have no worries.Don't hesitate to write us an email to get more information about 20 Ports Ethernet Switch With 16 PoE Ports 2 Uplink 2 SFP.

Specification of this 1000Mbps Unmanaged 16+4 Port 150W 250W 450W PoE Ethernet Switch

Item

Description

Power

Power Adapter Voltage

110-240V AC

Consumption

150W/250W/450W

Network

Connector

Network Port

1~ 16Port : 10/100/1000Mbps  1~16:POE Ethernet port

Uplink Port : two Ethernet 1000Mbps

 SFP 1000Mbps

Transmission DistanceAA

1~16 Port : 0 ~ 100m;

SFP: depends on the optical module

Transmission Medium

Cat5/5e/6 standard network cable

Network

Switch

Network Standard

IEEE 802.3, IEEE 802.3u,IEEE 802.1ab, IEEE 802.3x

Switching Capacity

22Gbps

Packet Forwarding Rate

14Mpps

MAC Table

4K

Power Over

Ethernet

POE Standard

IEEE 802.3af/at

POE Power Supply Type

End-Span(1/2+;3/6-)

PoE Power Consumption

af≤15.4W / at≤30W (every port)

LED Status

Indicator

VLAN/Extend

POE Ethernet LED

 Indicator

Power: 1 red light indicates that the power normal work

POE:16 yellow lights indicate that the POE is power on

Ethernet:20 green lights indicate that the Ethernet link and act;

Environmental

Working temperature

0℃~55℃

Relative Humidity

20~95%

Storage temperature

-20℃~70℃

Mechanical

Dimension (L×W×H)

440 mm *290 mm *45mm

Color

Black

Weight

3385g

Stability

MTBF

>30000h


Application of this 20 Ports Ethernet Switch with 16 PoE Ports 2 Uplink 2 SFP
